BEAT LIGHT

THE SUPERLIGHT HEART BEAT!

It’s performant, it’s precise, it’s extreme reliable and super light!
The BEAT light is the perfect wing for a very wide target group.

BEAT LIGHT DESIGNER’S NOTE

The BEAT light was originally not planned. But from the moment, we presented the BEAT, people were asking for the light version. As we see our main goal and motivation to offer the pilots out there the wings they want, we started to develop the light version of the BEAT. So here it is: the BEAT light: enjoy!

Hannes Papesh



Descrizione

BEAT LIGHT TECHNICAL FEATURES

The BEAT light is based on the BEAT: so 56 cells and a flat aspect ratio of 5.3. The BEAT light lines up between TENOR light and MAESTRO light.
Technically it is a somewhat slimmed down MAESTRO light with a few pinches of ALLEGRO (3 main lines), a little FANTASIA (intake) and of course SYMPHONIA (being extremely well balanced).

Even used light clothes, the BEAT light is very form stable and precise: “carving the sky”, was one of the feedbacks.

Like the BEAT, the BEAT light is mainly using covered lines. This is following the request of pilots who wanted more robust sheathed TECHNORA on brakes and stabilo.

BEAT LIGHT TECHNICAL DATA

BEAT light
size 18 20 22 23 24 26 28
number of cells 56 56 56 56 56 56 56
projected span m 8,29 8,74 9,18 9,4 9,61 10,02 10,40
projected area m² 17,74 19,72 21,73 22,77 23,79 25,89 27.89
projected aspect ratio 3,88 3,88 3,88 3,88 3,88 3,88 3,88
flat span m 10,51 11,07 11,63 11,9 12,17 12,69 13,76
flat area m² 20,8 23,11 25,48 26,7 27,9 30,37 32,71
flat aspect ratio 5,31 5,31 5,31 5,31 5,31 5,31 5,31
line length m 6,24 6,57 6,9 7,07 7,22 7,53 7,82
total line length m 250 260 270 280 290 300 330
maximum chord m 2,45 2,58 2,71 2,77 2,84 2,96 3,07
minimum chord m 0,66 0,7 0,73 0,75 0,77 0,8 0,83
weight kg 3 3,3 3,58 3,72 3,85 4,15 4,45
certified weight range kg 50-75 65-85 75-95 83-103 90-110 105-130 105-155
certification (EN/LTF) B B B B B B B
ext. weight range motor kg 50-130 65-130 75-170 83-170 90-170 105-170 105-200
certification DGAC ok ok ok ok ok ok i.A.
material Porcher Skytex 27 double coated
risers R08 (3+1)
riser length mm 500 540 540 540 540 540 540
speedway mm 150 150 180 180 180 200 200

BEAT LIGHT WEIGHT RANGES

BEAT LIGHT COLORS

BEAT LIGHT GUARANTEE

Like all other PHI wings, the BEAT light is covered by the PHI PROMISE GUARANTEE.
Every damage is repaired in the first year of usage.
